The MARANTEC COMFORT 370 is a 24 V DC garage door opener for compatible sectional and overhead door installations. With a maximum push and pull force of 850 N, it is specified for doors weighing up to 185 kg. For a villa or private garage, it brings convenient powered access while allowing the installation to be configured around the actual door and rail arrangement.
The Comfort 370 places particular emphasis on travel speed and illumination. Its maximum movement speed of 23.5 cm/s can shorten the powered part of an opening cycle, while two LED lighting modules help illuminate the garage near the operator. Total opening time still depends on door travel and the configured acceleration and stopping phases.
The published operating limits are 4 cycles per hour and 32 cycles per day. These figures should be considered alongside peak usage rather than just the number of people using the garage. Select the correct rail and door fittings, and confirm receiver and transmitter versions when replacing existing equipment.
Key Features
- 850 N maximum push/pull force for correctly balanced doors.
- 185 kg stated maximum door weight.
- Integrated controller and two 10-led modules.
- 868 MHz bi.linked radio platform with compatible receiver and controls.
- Suitable for compatible sectional and overhead door arrangements.
Technical Specifications
- Model: MARANTEC COMFORT 370.
- Motor: 24 V DC; mains supply: 230 V single phase.
- Maximum force: 850 N.
- Maximum speed: 23.5 cm/s.
- Maximum door weight: 185 kg.
- Maximum specified sectional door width: 5.5 m.
- Operating limit: 4 cycles/hour; 32 cycles/day.
- Lighting: Two 10-LED modules.
- Radio system: 868 MHz bi.linked.
Garage Compatibility and Installation
For a garage in Dubai, Sharjah, Abu Dhabi or elsewhere in the UAE, begin with the actual door measurements and operating pattern. Check headroom, rail travel, mounting points and the condition of rollers, hinges and counterbalance hardware. A powered opener should be fitted to a door that already moves freely and remains correctly balanced.
During commissioning, the installer should set opening and closing travel, test force response and any connected safety sensors, and demonstrate the manual release. Confirm the supplied rail, remote controls and optional accessories before ordering so the installation matches the access requirements of the property.
Frequently Asked Questions
Is maximum door weight the only selection criterion?
No. The door width, balance, travel, track arrangement and required number of cycles all affect suitability. Have the complete door assessed before selecting the motor.
Will my older Marantec remote work?
Check both the radio frequency and the coding system. A remote operating at the same frequency may still use a different protocol and need replacement.
Is a rail supplied with the motor?
Rail length and package contents must be confirmed for the selected installation. Choose a rail with sufficient travel for the door height and available garage space.
