BEA MATRIX-S220 Loop Detector for UAE Gate Automation
BEA MATRIX-S220 Loop Detector monitors an inductive loop installed in the driveway and provides a vehicle-detection signal to a compatible gate or parking barrier controller. Match the detector supply, loop configuration and output connections to the installation.
Technical Specifications
- Model: MATRIX-S220
- Brand: BEA
- Technology: Inductive Loop Detection
- Channels: Single Channel
- Power Supply: 230V AC ±10%
- Detection Modes: Presence / Pulse
- Presence Time: 1 Minute to Infinite
- Pulse Output Timing: 100 ms / 500 ms
- Inductance Range: 20 µH – 1000 µH
- Frequency Range: 20 kHz – 130 kHz
- Sensitivity Adjustment: 0.005% – 0.5%
- Reaction Time: Approx. 25 ms
- Power Consumption: Less than 2.5W
- Outputs: 2 Relay Outputs (5A Max)
- Protection Rating: IP40
- Operating Temperature: -30°C to +40°C
- Storage Temperature: -30°C to +70°C
- Connector Type: 11-pin Round Base
- Dimensions: 77 × 40 × 75 mm
- Weight: Less than 200g
Applications
Suitable for compatible villa entrances, residential compounds, commercial premises and industrial access systems in Dubai, Abu Dhabi, Sharjah and across the UAE. Final suitability depends on the gate equipment and site requirements.
Installation and Compatibility
Check the exact supply voltage, controller inputs, wiring diagram and loop arrangement before connection. Correct loop positioning and sensitivity adjustment are essential. Installation and commissioning should follow the equipment manufacturer's instructions.
Frequently Asked Questions
Will this fit my existing system?
Compatibility depends on the exact motor or barrier model and installation. Send the model details and photographs of the existing part for a compatibility check.
Is installation available in the UAE?
Contact Sliding Gate Motor UAE to confirm installation, setup and testing availability for your location.
